ENGINE SPECIFICATIONS
GX630 Honda air cooled engine
V-Twin cylinder, 4-stroke gasoline engine
Electric start
Charge coil 12V-17A

INCLUDED ACCESSORIES
Pressure gauge
Low oil alert
Quick connect for 12-V battery

PUMP UNIT SPECIFICATIONS
C.E.T. single stage centrifugal pump
Pump body made from high resistance aluminum alloy
Bronze impeller
Mechanical shaft seal
Exhaust priming system, guaranteed up to 20' (6 meter) lift
One 1 1/2" (38mm) delivery outlet
One 2 1/2" (65mm) suction inlet
Dimensions: Length: 19 3/4 (502 mm); Width: 24 1/4'' (615 mm); Height: 24 3/4'' (630 mm)
Weight: 147.4 lbs (67 kg)

MAX FLOW : 300 GPM
MAX PRESSURE : 205 PSI
240 GPM @ 50 PSI
125 GPM @ 150 PSI
60 GPM @ 200 PSI
